Capsule Filling Machine operation steps:
1. Press the green button in the "Power Switch" to turn on the power.
2. Slowly adjust the "vibration intensity adjustment knob" and turn it clockwise. At this time, the sorting tray integrated with the "vibration bracket" begins to vibrate, touch the sorting tray with your hand, and adjust to a certain vibration intensity by feeling.
3. Put the powder-filled capsule shells into the "powder-filled capsule shell sorting tray", about 300 capsules each time. Put the capsule caps into the "capsule cap sorting tray", about 300 capsules each time. The sorting tray is made of plexiglass plate, and there are many round holes in the shape of a funnel, the diameter of which corresponds to the diameter of the capsule number. At this time, the capsule shell of the vibrating worktable moves steadily back and forth, so that the pellets enter the plate hole one by one.
4. About 30 seconds, the powder-filled capsule shell and capsule cap will drop into the round hole with the opening facing upwards. In case of individual openings facing downwards, the capsule cap can be gently pressed down to pull out.
5. Hold the powder capsule shell connecting plate horizontally, and gently push in the lower part of the sorting tray, the powder capsule shell in the sorting tray will drop down into the hole of the connecting plate, and then take out the connecting plate. In the same way, remove the capsule cap with the capsule cap connecting plate.
6. A medicinal powder square plate with a bottom area of ​​500×500mm and a height of about 10mm on four sides can be prepared in advance, and the powder-containing capsules can be placed flat on the medicinal powder square plate. Then put the randomly equipped plexiglass frame on the powder capsule receiving plate, put the powder into the frame with a small bucket, and scrape the edge of the frame to fill the powder and scrape off the excess powder.
7. Use the randomly equipped capsule cap cover plate and place it on the capsule cap connecting plate. There are alignment holes for easy placement. Turn over the cap connecting plate of the capsule so that the opening of the capsule faces downwards, and put it on the powder-filled capsule connecting plate that has been filled with powder. There are also alignment holes for easy fitting.
8. Put the fitted capsule plate into the cavity under the "capsule cap forming plate", pull the "pressing rod" down by hand, and place it in place. There is no need to be careful of excessive force because there is a positioning mechanism to control the pressing down. high. Take out the nested capsule board, pour out the Custom Organic Capsules, and the filling is complete. You can cycle to the next board.
